ARMADILLO 10X - MH Equipment

The 10x offers the largest sweeping footprint of the PowerBoss Sweeper Product line. Rugged all-steel construction, a 2,000 lb./30ft3 hopper, and Kubota Tier IV engine ensure superior industrial reliability. Simple, all-hydraulic controls and no tools needed to change brushes and filters, maximize operator utilization. With a sweeping width of over 7 ft. the 10x from PowerBoss is able to tackle the largest indoor and outdoor cleaning needs.

Operators will find productivity gains with the 10x rotating hopper or “RTR”. This feature allows collected debris (while in operation) to be moved forward, resulting in additional “gained” hopper space. This allows for full utilization of the hopper and increases the amount of volume that can be collected in a single shift (similar to a trash compacter). The 10x was also engineered with dual synthetic dust filters which keep exiting dust below 3 microns and twin shaker motors ensure that filters remain clean. Based on environmental needs, HEPA and MERV filtration are available.  When preventative service or maintenance is needed, PowerSwing (engine pivots full 180 degrees) allows for faster service, less downtime and maximum engine accessibility.  Common applications for the 9x include mining, heavy duty manufacturing, parking, outdoor, high dust and severe environments.

Specifications

  • Weight: 4575 lbs
  • Performance: 217800 sq ft per hour
  • Width: 68 inch
  • Cleaning width: 72/84 inch
  • Hopper Capacity: 2000 lbs
  • Main Broom: 56 inch
  • Side Broom: 26 inch
  • Dust Filter: 180 sq ft
  • Length: 105.88 inch
  • Height: 55.38 inch

Features

  • RTR Full Use Hopper
  • No Tools Change Brushes and Filters
  • Oversized Curb Climbing Tires
  • Full Service 180-degree Swing-Out Engine
  • 84” Sweeping Width
  • Common Options Include Fully Enclosed Cab with Heat/AC, Overhead Guard, Safety Lights and Back-Up Alarm, HEPA, MERV
  • Industry Leading Warranty<
  • 2,000 lb. Full Rotating Hopper
  • Aggressive Twin Filter Shaker Motors
  • 56” Main Sweeping Broom
  • 30 ft3 Hopper Capacity
  • Variable Hopper Empty Height to 64”
  • Kubota Tier IV – LP, Gasoline or Diesel Engine
  • Dual Synthetic Panel Filters
  • Weather Proof Hydraulic Controls
  • Agricultural Grade All-Steel Construction
