PHOENIX 26 - MH Equipment

The Phoenix 24 and 28 have cylindrical brush decks with integrated sweeping function. The cylindrical deck is made of corrosion-resistant aluminum casting. The Phoenix 26 is a disc model equipped with Aqua-Stop. Two powerful brush motors guarantee an even cleaning result across the entire width of the machine. The direct Brush Release System (BRS) allows brushes to be changed quickly. Battery running time to suit the application, on-board charger standard. Phoenix 24 has a 19 gal solution tank and a 19.5 gal recovery tank. Phoenix 26 and 28 have a 19 gal solution tank and a 19.5 gal recovery tank. Flow-optimized dirty water tank with AFS (Anti Foam System) to protect the vacuum turbine. Large tank lid provides easy access for cleaning purposes. A new kind of squeegee with Quick Adjust System allows optimum pickup even on difficult floors. Quick-clamping device for squeegee makes replacement easier. Squeegee blade is highly-resistant to wear. Easy, ergonomic operation as a result of the compact, maneuverable construction. Simple, easy-to-understand controls ensure that the machine is easy to use and maintain. Ergonomic, adjustable speed regulation. Designed to give the operator more room for their feet while operating the Phoenix 24, 26 or 28. Designed to give the operator an excellent line of sight to the area that needs to be cleaned.

Specifications

  • Brush Type: Disc
  • Weight: 570.6 lbs (258.5 kg)
  • Brush Motor & RPM (Disc): .75 HP (2)
  • Cleaning width: 26 in (65 cm)
  • Number of Brushes: 2
  • Solution Capacity: 19.5 Gal (74 liters)
  • Vacuum Waterlift: 65 inches (165 cm)
  • Recovery Capacity: 19 Gal (72 liters)
  • Performance: 25,640 ft 2 /hr (2,382 m2 )
  • Theoretical Productivity (BD): 34,445 ft 2 /hr (3,200 m2 )
  • Squeegee Width: 37.4 in (95 cm)
  • Working Speed: 3.1 mph (5 km per hr)
