SJ3220/26 Skyjack

Equipment Features & Specs

  • Skyjack
  • SJ3220/26
  • Scissor Lifts

Let us Help You Find What You Need

Phone Icon (270) 842-3535
Mail Icon Request A Quote Price Tag Icon Financing
SJ3220
SJ3226
Work Height
25’ 6” (7.77 m)
31’ 6” (9.61 m)
Raised Platform Height
19’ 6” (5.94 m)
25’ 6” (7.78 m)
Lowered Platform Height
39” (0.99 m)
46” (1.17 m)
Overall Width
32” (0.81 m)
32” (0.81 m)
Overall Length
91.6” (2.32 m)
91.6” (2.32 m)
Stowed Height (Rails Up)
83” (2.10 m)
90” (2.29 m)
Stowed Height (Rails Down)
69” (1.75 m)
76” (1.93 m)
Platform Width (Inside Dimension)
28” (0.71 m)
28” (0.71 m)
Platform Length (Inside Dimension)
83” (2.11 m)
83” (2.11 m)
Extension Deck (Roll Out)
3’ (0.91 m)
3’ (0.91 m)
Wheelbase
69” (1.75 m)
69” (1.75 m)
Weight
3,917 lbs (1,776 kg)
4,190 lbs (1,900 kg)
Gradeability
25%
25%
Turning Radius (Inside)
43” (1.09 m)
43” (1.09 m)
Turning Radius (Outside)
104” (2.64 m)
104” (2.64 m)
Lift Time (With Rated Load)
28 sec
47 sec
Lower Time (With Rated Load)
24 sec
41 sec
Drive Speed (Stowed)
2.4 mph (3.9 km/h)
2.4 mph (3.9 km/h)
Drive Speed (Raised)
0.6 mph (1.0 km/h)
0.6 mph (1.0 km/h)
Maximum Drive Height
Full Height
Full Height
Capacity
900 lbs (408 kg)
900 lbs (408 kg)
Distributed Capacity (Main Platform)
600 lbs (272 kg)
250 lbs (113 kg)
Distributed Capacity (Extension Deck)
300 lbs (136 kg)
250 lbs (113 kg)
Local Floor Load (With Rated Load)
109 psi (749 kPa)
104 psi (718 kPa)
Overall Floor Load (With Rated Load
248 psf (1209 kg/ m2)
241 psf (1177 kg/ m2)
Maximum # of Persons
2
2
Tire Type
Solid, N/M
Solid, N/M
Tire Type
16 x 5 x 12
16 x 5 x 12
http://player.vimeo.com/video/149332291
