The compartment is your operator’s office, so we designed it for comfort and efficiency. This spacious, ergonomically designed workspace is built to maximize productivity and minimize operator fatigue.

• Low step height, wide cushioned floor and one-inch thick padded rubber floor mat for shift-long comfort
• Foot switch position that promotes a natural stance
  Unobstructed visibility through the mast
• Multi-function control handle can be rotated to one of three positions for a comfortable operating stance
• Retractable side gates with easy one-hand operation for side protection and quick access

Yale electric order pickers are engineered with state-of-the-art Smart-Glide™ technology.

This technology is a continuous height-sensing system that eliminates the “pogo” effect by providing stepless speed control, optimizing the maximum travel speed at various fork heights. The adjustment in speed is smooth, gradual and barely noticeable to the operator. Smart-Glide leads to faster travel speeds, improved acceleration and increased productivity, while helping maximize stability.

Performance is built into every Yale® lift truck, and the electric order picker series is no exception. State-of-the-art technology enables more efficient and reliable order picking workflows.

• Wire guidance system holds firmly, giving operators the security to focus on the pick task without worrying about steering
• Pallet clamp automatically centers and grips the pallet, with a foot-operated pedal that is easily actuated for quick pallet release
• Smart-Steer™ handle (optional) provides automatic return-to-center when released. The maximum required turn of the handle is 90 degrees from center to provide a full range of truck maneuverability.
• Standard multi-turn steering utilizes a stepper motor to provide increased sensitivity for accurate control and error detection.

Four model configurations to meet your application needs

OS030EF - STANDARD DUTY COUNTERBALANCE
Heights to 240”
24V system
AC drive and DC hoist
Single lift speed control
Maximum travel speed: 6 mph
Maximum lift speed: 40 ft/min
Maximum lower speed: 52 ft/min

OS030BF - HEAVY DUTY COUNTERBALANCE
Heights to 300”
24V system (optional 36V)
AC drive and optional AC hoist
Variable lift speed control
Maximum travel speed: 6.5 mph
Maximum lift speed: 67 ft/min
Maximum lower speed: 80 ft/min

SS030BF - STRADDLES LOADS
Heights to 360”
24V system (optional 36V)
AC drive and optional AC hoist
Variable lift speed control
Maximum travel speed: 6.5 mph
Maximum lift speed: 67 ft/min
Maximum lower speed: 80 ft/min

FS030BF - FURNITURE SELECTOR
Heights to 360”
24V system (optional 36V)
AC drive and DC hoist
Variable lift speed control
Maximum travel speed: 6.5 mph
Maximum lift speed: 67 ft/min
Maximum lower speed: 80 ft/min
