1250AJP

JLG

Location:

Unit:

Price: Contact for price

Ground to 120 ft in 95 seconds
Strong 100,000-psi steel and a dual 1,000 lb / 500 lb capacity give you stability and capacity
Equipped with a fuel-efficient Tier 4 engine

Capacity

500lbs

Load Weight

Max Lift Height

Power

Environment

Primary Task

Industry

Model Year

Truck Type

Meter

Upright Lift / Lower Height

Upright Type

Attachments

Valve Type

Fork Length

Tire Type

Seat Type

Battery Condition

Transmission

Phases

Machine Length	47 ft 6 in. / 14.48 m
Platform Capacity – Restricted	1000 lb / 453.59 kg
Swing	360 Degrees
Jib – Range of articulation	130 Degrees
Axle Oscillation	8 in. / 0.2 m
Swing Type	Continuous
Horizontal Jib Rotation	125 Degrees
Machine Width	8 ft 2 in. / 2.49 m
Capacity – Fuel Tank	31 gal. / 117.35 L
Drive Speed – 4WD	3.3 mph / 5.23 km/h
Capacity – Hydraulic Reservoir	53 gal. / 200.63 L
Machine Weight	44000 lb / 19958.06 kg
Up and Over Height	60 ft 6 in. / 18.44 m
Turning Radius – Outside (axles retracted)	22 ft 6 in. / 6.86 m
Horizontal Outreach	63 ft 2 in. / 19.25 m
Auxiliary Power	12 Volts DC
Transport Length	37 ft 7 in. / 11.46 m
Platform Dimension B	8 ft / 2.44 m
Overall Width (Axles Extended)	12 ft 6 in. / 3.81 m
Gradeability – 4WD	45 %
Platform Height	125 ft / 38.1 m
Turning Radius – Outside (axles extended)	19 ft 4 in. / 5.89 m
Engine Type – Diesel	DEUTZ TCD2.9L4 Tier 4 Final 74.2 hp
Machine Height	10 ft / 3.05 m
Ground Clearance	1 ft / 0.3 m
Tire Size	445/500710 Foam-Filled
Tailswing	3 ft / 0.91 m
Maximum Ground Bearing Pressure	100 psi / 7 Kg/cm2
