600AJ

JLG

Location:

Unit:

Price: Contact for price

Capacity

500lbs

Load Weight

Max Lift Height

Power

Environment

Primary Task

Industry

Model Year

Truck Type

Meter

Upright Lift / Lower Height

Upright Type

Attachments

Valve Type

Fork Length

Tire Type

Seat Type

Battery Condition

Transmission

Phases

Platform Dimension A	3 ft / 0.91 m
Machine Length	29 ft / 8.83 m
Platform Height	60 ft 7 in. / 18.47 m
Maximum Ground Bearing Pressure	75 psi / 5.25 Kg/cm2
Machine Width	8 ft 2 in. / 2.49 m
Swing Type	Continuous
Capacity – Hydraulic Reservoir	30.6 gal. / 115.83 L
Platform Dimension B	8 ft / 2.44 m
Horizontal Outreach	39 ft 9 in. / 12.12 m
Turning Radius – Outside (2WS)	17 ft 7 in. / 5.36 m
Tailswing	0 in. / 0 m
Up and Over Height	26 ft 7 in. / 8.1 m
Jib – Range of articulation	130 Degrees
Horizontal Jib Rotation	0 Degrees
Swing	360 Degrees
Auxiliary Power	12 Volts DC
Gradeability – 4WD	45 %
Gradeability – 2WD	30 %
Engine Type – Dual Fuel	Ford MSG425 84hp
Machine Height	8 ft 4 in. / 2.54 m
Drive Speed – 4WD	4.3 mph / 6.84 km/h
Machine Weight	22740 lb / 10314.69 kg
Axle Oscillation	8 in. / 0.2 m
Engine Type – Diesel	DEUTZ TD 2.9L Tier 4 Final 67 hp
Ground Clearance	1 ft / 0.29 m
Capacity – Fuel Tank	30 gal. / 113.56 L
Turning Radius – Outside (4WS)	11 ft 8 in. / 3.56 m
Tire Size	IN355/55D-6.25 Low Profile
