SJ4726/32
New Equipment / Aerial Lifts / SJ4726/32
SJ4726/32
Location:
Unit:
Price: Contact for price
Industry Leaders
Skyjack electric scissor lifts have been recognized as an industry leader for over a decade. Our DC scissor lifts are ideal for indoor work where accuracy and precision turns around sensitive material is critical.
- SGLE
- Flashing light
- Tool caddy
- Extended warranties
- DC light duty pipe rack
- Aircraft protection package
- Elevate
- Ac inverter
- Bio oil
- DC heavy duty pipe rack
- Board carrier
- EE rating package
- Non destructive testing
- 6’ (1.8 m) powered extension deck
- Full height spring hinged gate
- Battery options
- Dual flashing lights
| Capacity |
| Load Weight |
| Max Lift Height |
| Power |
| Environment |
| Primary Task |
| Industry |
| Model Year |
| Truck Type |
| Meter |
| Upright Lift / Lower Height |
| Upright Type |
| Valve Type |
| Fork Length |
| Tire Type |
| Seat Type |
| Battery Condition |
| Transmission |
| Phases |
Models and Specifications
| SJ4726 | SJ4732 | |
|---|---|---|
| Work Height | 31′ 8″ (9.65 m) | 37′ 8″ (11.48 m) |
| Raised Platform Height | 25’ 8” (7.82 m) | 31’ 8” (9.65 m) |
| Lowered Platform Height | 46” (1.17 m) | 50” (1.27 m) |
| Overall Width | 47” (1.19 m) | 47” (1.19 m) |
| Overall Length | 91.6” (2.32 m) | 91.6” (2.32 m) |
| Stowed Height (Rails Up) | 90” (2.29 m) | 94” (2.39 m) |
| Stowed Height (Rails Down) | 75” (1.90 m) | 78.5” (1.99 m) |
| Platform Width (Inside Dimension) | 42” (1.07 m) | 42” (1.07 m) |
| Platform Length (Inside Dimension) | 83” (2.11 m) | 83” (2.11 m) |
| Extension Deck (Roll Out) | 4’ (1.22 m) | 4’ (1.22 m) |
| Wheelbase | 69” (1.75 m) | 69” (1.75 m) |
| Weight | 5,537 lbs (2,511 kg) | 5,496 lbs (2,492 kg) |
| Gradeability | 25% | 25% |
| Turning Radius (Inside) | 28” (0.71 m) | 28” (0.71 m) |
| Turning Radius (Outside) | 104” (2.64 m) | 104” (2.64 m) |
| Lift Time (With Rated Load) | 52 sec | 50 sec |
| Lower Time (With Rated Load) | 32 sec | 30 sec |
| Drive Speed (Stowed) | 2.0 mph (3.2 km/h) | 2.0 mph (3.2 km/h) |
| Drive Speed (Raised) | 0.6 mph (1.0 km/h) | 0.6 mph (1.0 km/h) |
| Maximum Drive Height | Full Height | Full Height |
| Capacity | 1,000 lbs (454 kg) | 700 lbs (318 kg) |
| Distributed Capacity (Main Platform) | 700 lbs (318 kg) | 450 lbs (204 kg) |
| Distributed Capacity (Extension Deck) | 300 lbs (136 kg) | 250 lbs (113 kg) |
| Local Floor Load (With Rated Load) | 131 psi (903 kPa) | 124 psi (856 kPa) |
| Overall Floor Load (With Rated Load) | 234 psf (1143 kg/ m2) | 222 psf (1083 kg/ m2) |
| Maximum # of Persons | 3 | 2 |
| Tire Type | Solid, N/M | Solid, N/M |
| Tire Size | 16 x 5 x 12 | 16 x 5 x 12 |
Overview
