SJ6826/32 RT
New Equipment / Aerial Lifts / SJ6826/32 RT
SJ6826/32 RT
Location:
Unit:
Price: Contact for price
Superior Gradeability
Skyjack rough terrain scissor lifts boast impressive platform capacities and industry-leading gradeability (up to 50%). With crossover symmetrical four-wheel drive, these machines deliver maximum torque to all wheels for superior all terrain performance.
- Bio oil
- Diesel scrubber
- Elevate
- Flashing light
- SGLE
- Cold weather package
- Non destructive testing
- Extended warranties
- RT heavy duty pipe rack
- Independent/auto levelling outriggers
- Tire options
- Tool caddy
- Positive air shut-off valve
| Capacity |
| Load Weight |
| Max Lift Height |
| Power | 24.8 HP Kubota |
| Environment |
| Primary Task |
| Industry |
| Model Year |
| Truck Type |
| Meter |
| Upright Lift / Lower Height |
| Upright Type |
| Valve Type |
| Fork Length |
| Tire Type |
| Seat Type |
| Battery Condition |
| Transmission |
| Phases |
Models and Specifications
| SJ6826 RT | SJ6832 RT | |
|---|---|---|
| Work Height | 32’ (9.75 m) | 38’ (11.58 m) |
| Raised Platform Height | 26’ (7.92 m) | 32’ (9.75 m) |
| Lowered Platform Height | 48.5” (1.23 m) | 54” (1.37 m) |
| Overall Width | 69.5” (1.76 m) | 69.5” (1.76 m) |
| Overall Length | 107” (2.72 m) | 107” (2.72 m) |
| Stowed Height (Rails Up) | 93.5” (2.38 m) | 99” (2.51 m) |
| Stowed Height (Rails Down) | 63.5” (1.61 m) | 69” (1.75 m) |
| Platform Width (Inside Dimension) | 56” (1.42 m) | 56” (1.42 m) |
| Platform Length (Inside Dimension) | 96” (2.44 m) | 96” (2.44 m) |
| Extension Deck | 5’ (1.52 m) | 5’ (1.52 m) |
| Ground Clearance | 8” (0.20 m) | 8” (0.20 m) |
| Weight | 6,460 lbs (2,930 kg) | 7,590 lbs (3,443 kg) |
| Gradeability | 50% | 40% |
| Turning Radius (Inside) | 60” (1.52 m) | 60” (1.52 m) |
| Turning Radius (Outside) | 156” (3.96 m) | 156” (3.96 m) |
| Lift Time (With Rated Load) | 36 sec | 39 sec |
| Lower Time (With Rated Load) | 36 sec | 36 sec |
| Drive Speed (Stowed) | 3.8 mph (6.1 km/h) | 3.8 mph (6.1 km/h) |
| Drive Speed (Raised) | 0.4 mph (0.6 km/h) | 0.4 mph (0.6 km/h) |
| Maximum Drive Height | Full Height | Full Height |
| Capacity | 1,250 lbs (567 kg) | 1,000 lbs (454 kg) |
| Distributed Capacity (Main Platform) | 950 lbs (431 kg) | 700 lbs (318 kg) |
| Distributed Capacity (Extension Deck) | 300 lbs (136 kg) | 300 lbs (136 kg) |
| Local Floor Load (With Rated Load) | 190 psi (1,310 kPa) | 216 psi (1,500 kPa) |
| Overall Floor Load (With Rated Load) | 170 psf (830 kg/m2) | 200 psf (976 kg/m2) |
| Maximum # of Persons | 4 | 4 |
| Tire Type | Foam-Filled | Foam-Filled |
| Tire Size | 26 x 12 | 26 x 12 |
| Diesel Engine | 24.8 HP Kubota | 24.8 HP Kubota |
| Fuel Tank | 23 gal (87 L) | 23 gal (87 L) |
| Hydraulic Reservoir | 23 gal (87 L) | 23 gal (87 L) |
Overview
