T26E

JLG

Location:

Unit:

Price: Contact for price

Vertical telescopic mast with a jib lets you reach up and over obstacles in tighter spaces than an articulating boom.
Non-marking tires and efficient electric power for indoor jobs.
25% gradeability for outside work.

Capacity

500lbs

Load Weight

Max Lift Height

Power

Environment

Primary Task

Industry

Model Year

Truck Type

Meter

Upright Lift / Lower Height

Upright Type

Attachments

Valve Type

Fork Length

Tire Type

Seat Type

Battery Condition

Transmission

Phases

Jib – Range of articulation	127 Degrees
Machine Length	9 ft 3 in. / 2.82 m
Platform Dimension A	2 ft 5 in. / 0.74 m
Drive Speed – Platform Lowered	3.4 mph / 5.47 km/h
Swing Type	Non-Continuous
Machine Height	6 ft 7 in. / 1.99 m
Wheelbase	3 ft 11 in. / 1.19 m
Machine Weight	6834 lb / 3099.85 kg
Turning Radius – Outside	6 ft 7 in. / 2.01 m
Swing	360 Degrees
Batteries	240 amp-hr
Machine Width	3 ft 9 in. / 1.14 m
Electrical System	24 Volts DC
Horizontal Outreach	8 ft 8 in. / 2.64 m
Platform Height	26 ft 5 in. / 8.05 m
Capacity – Hydraulic Reservoir	1.9 gal. / 7 L
Ground Clearance	3 in. / 0.08 m
Gradeability – 2WD	25 %
Tire Size	125 x 406 non-marking
Horizontal Jib Rotation	0 Degrees
Tailswing	2 in. / 0.06 m
Up and Over Height	21 ft 8 in. / 6.6 m
Platform Dimension B	2 ft 9 in. / 0.84 m
