1055
New Equipment / Aerial Lifts / 1055
1055
Location:
Unit:
Price: Contact for price
Key Specs
- Maximum Lift Capacity: 10000 lb / 4535.92 kg
- Outriggers Up Max Lift Height: 55 ft / 16.76 m
- Maximum Lift Height: 55 ft / 16.76 m
- Maximum Reach: 42 ft / 12.8 m
Key Features
- Enhanced operator comfort—spacious cab, intuitive single joystick and integrated arm rest
- Maximum serviceability— extended service intervals, easy-to-access parts and durable components for less overall maintenance
- Greater operator confidence— better visibility, Stabil-Trak rear axle stabilization, precision gravity lowering system, optional reverse sensing system and reversing camera
- Increased versatility—wide range of attachment options
| Capacity | 10000lbs |
| Load Weight |
| Max Lift Height |
| Power |
| Environment |
| Primary Task |
| Industry |
| Model Year |
| Truck Type |
| Meter |
| Upright Lift / Lower Height |
| Upright Type |
| Valve Type |
| Fork Length |
| Tire Type |
| Seat Type |
| Battery Condition |
| Transmission |
| Phases |
| Lift Capacity at Full Height | 5000 lb / 2267.96 kg |
|---|---|
| Maximum Reach | 42 ft / 12.8 m |
| Speed – Maximum Travel | 20 mph / 32.19 km/h |
| Axle-Front | High Bias, Limited Slip |
| Maximum Lift Capacity | 10000 lb / 4535.92 kg |
| Maximum Engine RPM | 1500 rpm |
| Transmission Type | Powershift |
| Outriggers Up Max Lift Height | 55 ft / 16.76 m |
| Operating Vehicle Weight | 31559 lb / 14314.92 kg |
| Axle-Rear | Planetary |
| Machine Width | 8 ft 5 in. / 2.56 m |
| Speed – Maximum Lower | 11 sec. |
| Outriggers or Stabilizers | Yes |
| Machine Length | 20 ft 1 in. / 6.12 m |
| Service Brake Type | Wet Multi-Disc |
| Capacity – Fuel Tank | 38.3 gal. / 144.98 L |
| Speed – Maximum Lift | 14 sec. |
| Drawbar Pull | 25400 lb / 11521.25 kg |
| Lift Capacity at Max Reach | 3000 lb / 1360.78 kg |
| Engine Model | QSF3.8L Tier 4 F |
| Wheelbase | 11 ft 6 in. / 3.49 m |
| Speed – Maximum Telescope In | 15 sec. |
| Engine Manufacturer | Cummins |
| Ground Clearance | 1 ft 6 in. / 0.46 m |
| Speed – Maximum Telescope Out | 16 sec. |
| Frame Leveling | 10 Degrees |
| Engine Horsepower | 130 hp / 96.98 kW |
| Function Pump Type | Load Sensing Piston |
| Transmission – Nr Reverse Gears | 3 |
| Transmission – Nr Forward Gears Standard | 4 |
| Tire Size | 400/75-28 |
| Load Center | 2 ft / 0.61 m |
| Outside Turning Radius | 14 ft / 4.27 m |
| Machine Height | 8 ft 4 in. / 2.54 m |
