SJ519 TH
New Equipment / Aerial Lifts / SJ519 TH
SJ519 TH
Location:
Unit:
Price: Contact for price
Easily Serviceable
Skyjack telehandlers extend our principle of simple reliability into material handling equipment. Our TH series is designed with all major service points easily accessible, limiting downtime and increasing our customers’ utilization. With a variety of proprietary features, Skyjack’s TH series offer the rental industry’s best life cycle value.
- Tilt steering
- Road light package
- Drive speed select dial
- Service convenience package
- Non destructive testing
- Cold weather package
- Attachments
- Air conditioning (closed cab only)
- Closed cab
- Backup sensor and camera
- Backup sensor
- Work light package
- Rotating beacon
- Partially enclosed cab (adds front & top windows, wipers)
- Elevate
- Extended warranties
- Four wheel fenders
- Fork options
- Hydraulic carriage connect
- Fire extinguisher bracket
- Positive air shut-off valve
- Carriage options
- Boom light package
| Capacity |
| Load Weight | 10,500 lbs (4,763 kg) |
| Max Lift Height | 19’ 1” (5.82m) |
| Power | 74 hp/184 lb-ft Deutz TCD 2.2L T4F |
| Environment |
| Primary Task |
| Industry |
| Model Year |
| Truck Type |
| Meter |
| Upright Lift / Lower Height |
| Upright Type |
| Valve Type |
| Fork Length |
| Tire Type |
| Seat Type |
| Battery Condition |
| Transmission |
| Phases |
Models and Specifications
| SJ519 TH | ||
|---|---|---|
| Overall Width | 5’ 11.5” (1.81 m) | |
| Ground Clearance | 11″ (27.94 cm) | |
| Wheelbase | 8′ 1″ (2.46 m) | |
| Turning Radius (Outside) | 125” (3.17 m) | |
| Fuel Tank | 15.1 gallon (57 L) | |
| Hydraulic Reservoir | 18.5 gallon (70 L) | |
| Breakout force | 10,600 lbs | |
| Maximum Lift Capacity | 5,500 lbs (2,495 kg) | |
| Maximum Lift Height | 19’ 1” (5.82m) | |
| Maximum Forward Reach | 11’ 1” (3.38 m) | |
| Rated Lift Capacity @ Maximum Height | 4,400 lbs (1,996 kg) | |
| Rated Lift Capacity @ Maximum Reach | 2,000 lbs (907 kg) | |
| O/A Length – Less Forks | 13’ 5” (4.09 m) | |
| Overall Height – Stowed | 6’ 4” (1.93 m) | |
| Operating Weight | 10,500 lbs (4,763 kg) | |
| Engine | 74 hp/184 lb-ft Deutz TCD 2.2L T4F | |
| Max Travel Speed – Forward | 15mph (24 km/h) | |
| Transmission | Hydrostatic, 1 F/R | |
| Axles | Dana | |
| Steering | 3 Mode (Front Wheel, 4 Wheel, Crab) | |
| Tires | Pneumatic 12 x 16.5 12PR Grip Lug | |
| Drawbar Pull | 8,700 lbs |
