Location:
Unit:
Price: Contact for price
Just 30″ wide, this stand-up will take you and your loads just about anywhere, even through narrow doorways. The ideal tow tractor for casinos, textile plants and other tight spaces requiring stop-and-go operations. Its impressive towing/picking abilities also make it a good stock chaser alternative. Large dual front wheels ensure a smooth and stable ride; self-adjusting large drum brakes allow for safe and sudden stopping. Ergonomic light touch controls, padded backrest and 360º visibility.
Key Features:
| Capacity |
| Load Weight |
| Max Lift Height |
| Power |
| Environment |
| Primary Task |
| Industry |
| Model Year |
| Truck Type |
| Meter |
| Upright Lift / Lower Height |
| Upright Type |
| Attachments |
| Valve Type |
| Fork Length |
| Tire Type |
| Seat Type |
| Battery Condition |
| Transmission |
| Phases |
Key Features:
| 24V | |
|---|---|
| Passengers | 1 |
| Load Capacity | 300 lbs. |
| Towing Capacity | 4,000 lbs. |
| Speed | 5 mph |
| Turning Radius | 53 “ |
| POWERTRAIN | |
| Motor | 6 hp shunt motor |
| Drive Axle | Helical gear differential |
| Transmission | Direct drive |
| Controller | SEPEX Electronic speed controller, Single right-hand side foot treadle for speed and brake control |
| ENERGY | |
| Voltage | 24V |
| Battery | Four 6V-220AH batteries |
| Charger | High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC |
| CHASSIS | |
| Body | 14-G diamond-plate steel body, tubular frame |
| Suspension | Dual front wheels to ensure the stability |
| Brakes | Self-adjusting H.D. drum brakes, regenerative braking |
| Wheels | 4.8×8 LRB pneumatic tires |
| Steering | Automotive Steering Wheel |
| Seats | Padded backrest |
| EQUIPMENT | |
| Lights | LED headlight |
| Indicators | Battery status indicator |
| Accessories | |
| Safety | Reverse alarm, Deadman foot switch, Horn |
| VEHICLE | |
| Weight | 840 lbs. |
| Height | 50″ |
| Length | 56″ |
| Width | 30″ |
| Wheel Base | 36″ |
| DECK | |
| Deck Height | 35″ |
| Deck Length | 13″ |
| Deck Width | 30″ |
| BATTERY | |
| Battery Weight | |
| Battery Height | |
| Battery Length | |
| Battery Width | |
*Empty* Leave this here for styling purposes
| 24V | |
|---|---|
| Passengers | 1 |
| Load Capacity | 300 lbs. |
| Towing Capacity | 4,000 lbs. |
| Speed | 5 mph |
| Turning Radius | 53 “ |
| POWERTRAIN | |
| Motor | 6 hp shunt motor |
| Drive Axle | Helical gear differential |
| Transmission | Direct drive |
| Controller | SEPEX Electronic speed controller, Single right-hand side foot treadle for speed and brake control |
| ENERGY | |
| Voltage | 24V |
| Battery | Four 6V-220AH batteries |
| Charger | High-Frequency Charger, improves battery performance, prevents current surge, 50/60HZ, 110/220VAC |
| CHASSIS | |
| Body | 14-G diamond-plate steel body, tubular frame |
| Suspension | Dual front wheels to ensure the stability |
| Brakes | Self-adjusting H.D. drum brakes, regenerative braking |
| Wheels | 4.8×8 LRB pneumatic tires |
| Steering | Automotive Steering Wheel |
| Seats | Padded backrest |
| EQUIPMENT | |
| Lights | LED headlight |
| Indicators | Battery status indicator |
| Accessories | |
| Safety | Reverse alarm, Deadman foot switch, Horn |
| VEHICLE | |
| Weight | 840 lbs. |
| Height | 50″ |
| Length | 56″ |
| Width | 30″ |
| Wheel Base | 36″ |
| DECK | |
| Deck Height | 35″ |
| Deck Length | 13″ |
| Deck Width | 30″ |
| BATTERY | |
| Battery Weight | |
| Battery Height | |
| Battery Length | |
| Battery Width | |
