Fusion Passenger 4+2 Electric Cart
What to take the next step?
Move up to six people efficiently and comfortably
The Fusion 4+2 comfortably shuttles up to six people and is packed with safety and reliability features like three-point seat belts, backup cameras, noise emitters, front brush guards, and a full five-year warranty on our lithium-ion battery. The 4+2 can be used anywhere you need to efficiently move people in applications like parking shuttles, hospitality guest transport, and employee movement in localized areas, like airports, industrial plants, college and university campuses, resorts, job sites, zoos and more. When you only need to carry four or fewer, the rear seat flips down to convert to a flatbed for cargo. The Fusion 4+2 is a versatile people-moving solution for your fleet.
Specifications
- Motor: 5KW / 6.8 HP
- Controller: 450 Amp Programmable
- Drivetrain: 16:1 High Speed Rear Axle
- Speed: 19 mph (30.4 Km/H)/ 25 mph (40.2 Km/H)
- Battery: 51.2V 105Ah Marxon® Lithium-Ion Pack With Heating Module
- Charger: Onboard - 20 Amp 120V
- Range: 30 mi (48.3km)
- Battery Level Indicator: Digital Touch Screen
- Chassis: E-Coat And Powder Coated Steel Frame
- Suspension: Heavy Duty Coil Over Shocks
- Ground Clearance: 6.5” (16.5 cm)
- Brakes: 4 Wheel Premium Hydraulic Disc Brakes
- Park Brakes: Electro Magnetic, Automatically Actuated Once Vehicle Is Stopped, Released When Accelerator Peddle Is Engaged
- Wheels And Tires: Black Aluminum, 225/55-12
- Turning Radius: 120” (304.8 cm)
- Vehicle Capacity: 6 People
- Overall Dimensions: 145" x 48" x 78" (368.3cm x 121.9cm x 198.1cm)
- Utility Bed Dimensions: -
- Utility Bed: -
- Utility Bed Capacity: -
- Curb Weight: 1,102 lbs (499.8 kg)
- Payload: 1,124 lbs (509.8 kg)
- Tow Capacity: 2,000 Lbs (907.2 kg)
- Electronics: Digital Touch Screen Speedometer, Hazard Switch, USB Power Switch
- Body Color: White
- Seats: Black Bolstered Seats
- Warranty: 2-Year Full Car / 5-Year Full Battery
Additional Information
Safety is Standard
- 3-Point Seat Belts
- Pedestrian Noise Emitter + Back-Up Alarm & Camera
- Side & Center Mounted Rearview Mirrors
- DOT Glass Windshield With Wiper
Reliability is Standard
-
Bluetooth Diagnostic App
-
Rugged Front Bumper
-
Powder And E-Coat Frame
Performance is Standard
-
5.3 kWh Marxon®Lithium-Ion with Full 5-Year Warranty
-
5kW AC Motor
-
450 Amp Controller
Fusion vehicles are well-equipped with safety, reliability, and utility features designed to meet the needs of commercial and government fleet operators.
